Walls are designed for one-way shear along their sides. It is not necessary to check wall ends for punching shear.
In two-way floor design it is permissible to (i) use PT in 1-direction, rebar in other; (ii) PT in 2 directions; or (iii) rebar in both
Grouted tendon crack evaluation? How to? Click on this http://www.adaptsoft.com/forum/bijan/TN402_grouted_investigation_aalami.pdf
How to evaluate a cracked slab reinforced with unbonded tendons http://www.adaptsoft.com/forum/bijan/TN401_unbonded_investigation_aalami.pdf
A simplified way of estimating bending capacity of a PT section is to replace each grouted tendon by 4 times its area in rebar
Substituting a conventionally reinforced mat (raft) foundation by a post-tensioned alternative can reduce the mat thickness by 50%.
Unlike others, US codes do not specify a minimum rebar area for PT members, instead they specify a minimum precompression from prestressing
While not required by building code, a number of engineers in California place a mesh on top of first couple of PT levels above foundation
Design of a post-tensioned member requires 3checks: Serviceability (SLS); Strength (ULS) and Initial stressing (Transfer of Prestressing).
Unlike elevated floors, where design includes serviceability and strength, ground-supported PT slabs are checked for serviceability only
The largest tonnage of post-tensioning used in the United States is for slab foundation of low residential or light industrial buildings.
Did you know that the long-term stress losses in grouted tendon is much less than unbonded tendons? But grouted tendons have larger friction
In most residential and commercial buildings, economical post-tensioning can be achieved by balancing 60 to 80% of critical span dead load
Closure (delay strips) to mitigate cracking from restraint of supports apply to first couple of PT floors above foundation, not upper levels
Ground supported post-tensioned industrial floors are cast on two layers of plastic.The friction coefficient used is between 0.4 and 0.6
Grouted tendons are less effective than unbonded ones in service condition due to high friction, but more effective in developing strength
Practically all recent high rise buildings in high seismic risk San Francisco are built using PT slabs
Did you know there is no limit for tensile stresses in PT floors using European Code (EC2 ENV 1992-1-1:2004). There is one in ACI-318
Listen to Bijan explaining how to evaluate the vibration acceptability of concrete floors on Tue Feb 8 at ACI SF Cahpter 6 PM SJSU, San Jose
Check the flyer - post-tensioning design course in London http://workspace.imperial.ac.uk/cpd/public/PostTension2010%20_with%20insert.pdf
