Tobias🌾 @TobisLab

Electronics Design & Embedded Software ⚡️| CNC Hobbyist 🔧 | Sometimes I post about stuff I'm working on 💡 Germany Joined July 2014

Tweets

550
Followers

5K
Following

415
Likes

4K

Lukas Henkel @QVHenkel

5 months ago

I've designed a small stand-alone case for the mechanical keyboard module I'm using in the open-source laptop design. It's still missing the wireless interface/USB hub/card reader PCB though

10 33 406 19K 88

Download Image

Lukas Henkel @QVHenkel

5 months ago

Time to assemble the Cherry MX keyboard version 😊

7 11 318 15K 32

Download Image

natalie @natalie_thenerd

8 months ago

Finally uploaded my DS Lite copper scans ko-fi.com/i/IY8Y21A27ZN

4 4 36 2K 2

Tobias🌾 @TobisLab

8 months ago

This cute little voltage regulator makes 0603 capacitors look huge by comparison. 😅

13 15 459 17K 41

Download Image

Tobias🌾 @TobisLab

8 months ago

This happens when capacitors get a little too cozy during reflow.🧐

28 13 472 22K 26

Download Image

Tobias🌾 @TobisLab

8 months ago

First board assembled. 😇 Also decided to get the housing 3D-printed, rather than trying to mill it myself, for the time being.

19 29 813 42K 159

Download Image

Finally working on some electronics stuff again. Got 2 boards that I need to assemble. I've spent most of the last year building the CNC, so it's been a while. Maybe I should get some fresh solder paste. 🤔

1 2 30 3K 6

Download Image

Tobias🌾 @TobisLab

9 months ago

Tried milling M2 threads for this part, which worked surprisingly well. I thought for sure I was going to break this tiny thread mill. 😅 But I have a few more parts in the works that also require M2 threads, so there will still be enough opportunities for me to break it. 🙃

1 0 17 2K 3

Download Image

Marco Reps @MarcoReps

9 months ago

world class 8.5 digit multimeter btw

16 14 355 17K 41

Download Image

Tobias🌾 @TobisLab

9 months ago

Was looking through the config files of my cnc controller and found this. Guessing this is used to check if the config file is complete? Love it! ☕😄

1 0 15 2K 0

Download Image

Tobias🌾 @TobisLab

9 months ago

This part will be interesting to machine. I'm not even sure this will even work with my current setup 😅. I'll need to add a 4th axis for sure.

1 0 17 2K 5

Download Image

natalie @natalie_thenerd

12 months ago

I just want to boost my board scans repo, which contains copper and solder mask scans of the Game Boy line + more. I'm always working on it in the background github.com/nataliethenerd…
